Porcelain Housed Fuse Cutout 12-15kV 110kV BIL

Specification
      Rated Voltage(kV)                                          15
      Rated Current(A)                                         100/200
      Breaking Current(A)                              10000/12000
      Impulse Voltage(BIL)                                     110
Power-frequency withstand voltage                       40
      Leakage distence(mm)                                    250
      Weight(kg)                                                     6.8/7.3
      Dimensions(cm)                                         37.5*33*11

Other precise parameters are presented in our website.with more than 14years experience ,our company could offer various Fuse Cutout in the customers need.If you really interested in our products,we could send you
samples.Thank you for your attention
