Security Layer 3 L3 Routing Switches Series:LB5024
cenny[at]veecom.com.cn
Description
Security Layer 3(L3) Routing Switches
Introduce
Features
Advanced Security
As nowadays network facing all kinds of security threats, secret leakage and attacks, LB5024 series security intelligent multi-layer switch is equipped with advanced security features to guarantee the safe operation of the network.
Supports comprehensive ACL access control policies, including: user MAC address based ACL, IP protocol (TCP/UDP) based ACL, TCP port number based ACL, UDP port number based and time based ACL;
Can identify legal service terminals with bounded VLAN-IP-MAC; supports user access control protocol 802.1x, provides more efficient user port control than the traditional method; The port MAC address limitation function can control the host number accessing the specified port;
Supports PVLAN, offers strict port segregation within 802.1Q VLAN, ensures high security while ensuring service operation; Patented CPU protection technique checks and filters the data sent to the CPU to avoid malicious attack;
Several authentications for protocols such as RIP, OSPF, etc. (plain text authentication, MD5 authentication) to ensure the controllability of the route and network topology, offering higher security;
Flexible QoS
LB5024 series security intelligent multi-layer switch supports intelligent QoS to meet the high service quality demand of voice, video and other real-time multimedia services by following technologies:
>>Priority based on IEEE802.1P tagged information and quintuple flow classification service;
>>Supports flow-based multilayer CoS and ToS to satisfy the demand of real-time multimedia service such as video conference;
>>Self-defined multilayer flow classification rules, with 1024 flow rules supported in one device;
>>8 priority queues supported per port, with congestion prevention and flow-shaping;
Comprehensive routing protocol support
>>LB5024 series security intelligent multi-layer switch supports a rich set of routing technology which covers almost all current routing technologies.
>>Supports unicast routing protocols: RIP V1, RIP V2, OSPF, static routing;
>>Supports multicast routing protocols: IGMP, PIM-SM;
>>Supports redundancy backup protocol: VRRP.
Convenient Maintenance and Control
Supports NM methods such as SNMP, CLI, RMON, TELNET, WEB; Supports BOOTP,TFTP and FTP for fast software upgrading.
Overview
LB5024 series security intelligent multi-layer switch is a new-generation switch for networks demanding security, multi-service and high performance. Besides the large capacity and high performance of the traditional layer 3 switches, it also features advanced security. It is the premium choice as the layer 3 switch in the convergence layer for middle-sized MAN, the core switch for communities or the access switch for enterprise users.
LB5024 series includes two products:
LB5024TS series:Full wire-speed security intelligent multi-layer switch with all-1000M interfaces.4 10/100/1000MBase-T interfaces, 4 1000M SFP combo interfaces.
LB5024ST series:Full wire-speed security intelligent multi-layer switch with all-1000M interfaces.24 1000M SFP interfaces, 4 10/100/1000MBase-T combo interfaces.
Specifications
Feature Description LB5024ST LB5024TS
System
Port Number 24 1000M SFP interfaces;4 10/100/1000 Base-T COMBO interfaces 24 10/100/1000 Base-T interfaces;4 1000M SFP COMBO interfaces
Switching Capacity 48G
Packet Forward Capability >35.7Mpps
Power Consumption <70W
Basic Performance
MAC Address Table 32K
Routing Table Entries 8K
Buffer Capacity Shared 32M
Forwarding Mode Store-and-forward
Network and Flow Control
PVLAN Yes
VLAN 802.1Q 4k
QoS 8 priority queues for each port; support for flow shaping and rich scheduling methods
Queue Dispatching Methods WRR,SP,WRR+SP
Port Convergence Supports FE, GE port convergence; maximum 32 groups with 8 ports at most in each group
Routing Protocols
Unicast Static Routing, RIP V1/V2, OSPF V2
Multicast IGMP, PIM-SM
Policy Routing Yes
Num of Routing Interfaces 512
Security Feature
802.1X Yes
Web portal Yes
ACL 1K
MAC address limitation Yes
Broadcast Strom Suppression Yes
CPU Protection Yes
Port Speed Limitation 8K granularity
Management Features
SNMP SNMP V1 /V2c
RMON 1,2,3,9
HTTP Yes
CLI Yes
Dimension (L*W *H) 443mm*360mm*44.5mm 443mm*280mm*66.7mm
Working Environment 0~40oC , 10-90% non-condensing
Weight <6.5Kg
Ordering Information
Type Description Power
LB5024ST 24 (1000Base SFP interfaces) + 4 (10/100/1000M Base-T COMBO) AC 220V
LB5024TS 24 (10/100/1000M Base-T) + 4 (1000M Base-SFP interfaces COMBO) AC 220V
SP-GTX (SFP) GE-TX SFP module-GE-100 meters -RJ45-3.3V
SP-GSX (SFP) SFP optical module-GE-multimode-850nm-550meter-LC
optical connector-3.3v
SP-GLX (SFP) SFP optical module-GE-single mode-1310nm-10 kilometer-LC optical connector-3.3v
