1.Auto-Striper
This has a very unique and compact design and located inside the cylinder making it possible to set up the yarn carriers, inspect and work on the machine much easier compared with conventional type striper machines. On each respective striper finger is equipped with trapper cutter which made it possible to knit different types of yarns (fashion yarn, filament and spun yarns) or different yarn count yarns knitted fabrics. Further, as the Auto-Striper is constructed with mechanical parts, the solenoid for each respective striper is not required, so complicated circuits and enormous amplifier is not required, so maintenance of the machine is simple.
By this unique auto-Striper, at one feeder can have multi-fingers operate and synchronously feed yarns (up to 4 fingers possible) and knit them at the same time, and further have facility of having all fingers in non-yarn feeding condition, so in case of in-lay pattern, it is possible to knit stripe pattern where with and without in-lay yarns.
2.Japan WAC Control Panel and Sensor unit for Auto-Striper
With memory function, the computer control thread adjustment system can control 4 colors thread and can word as you required .Hi-tech man-machine interface liquid touch screen facilities the internal programmed modification so as to change the width of colored strip fabric. Equipping additional elastic yarn feed device, it can produce long range elastic colored stripe fabric.
3.Fabric types and derivative patterns
Through needles selecting and cams arrangement the machine can produce plain jersey, 1×1 tuck, 2×2 tuck, other tuck stitches, Float stitch, Inlay pattern, Crepe, Mini-jacquard, any one of above combined with striping. By using the multi-functional yarn feeders, equally and stably adding Lycra into the stitch is very easy.
|
