Features:
1. Infra-red LEDs for night-time vision, Effective night vision range: 8m
2.420TV lines clear picture display
3. Built-in microphone for audio monitoring
4. Min. 100m transmission distance without block

Specifications:
Transmission Frequency ISM: 2.414~2.468 GHz
Transmission Power: 10mW/CE; 2mW/FCC
Unobstructed Effective Range: 100m(Min. )
Modulation Mode: FM
Operating Temperature: -10 ~ +50(º C) / +14~ +122(º F)
Storage Temperature: -20 ~ +60(º C) / -4 ~ +140(º F)
Operating Humidity: or so 85%RH

CAMERA:
Imaging Sensor Type: Vimicro 0702 CMOS
Picture Total Pixels PAL: 628 x 582 Pixels;
NTSC: 510 x 492 Pixels
Horizontal Resolution: 420 TV Lines
View Angle PAL: 60; NTSC: 40 or so
Minimum Illumination: 0Lux
Night Vision Range: 8m
BandWidth: 20M
Angular Field of View: 45degree (F=6mm)
Dimension: 70mm*50mm*35mm
Weight: 70g
Power Supply: DC +12V

Receiver:
Antenna: 50 ohm SMA
Receiving Sensitivity: -85dBm
Video Output Signal Level: 1.1Vpp, 0.2Vpp@75 ohm, S/N >38dM
Audio Output Signal Level: 3.0Vpp, 1Vpp@600 ohm
Dimension: 100mm*80mm*30mm
Weight: 120g
Power Supply: DC +12V
