ST-300WA Auto Power(DC12V) Inverter-300W
Detailed Product Description
Specifications :
1. Input voltage Range: DC11-15V
2. Output voltage: AC220V/110V±10%
3. Output frequency: 50Hz±3Hz
3. Fuse: 10A/15A/20A/40A/70A
4. Low battery alarm(nominal): 10.4-11.0v
5. Low battery shutdown point(nominal): 9.7-10.3v
6. High battery shutdown point(nominal): 14.5-15.5v
7. Battery drain with on AC(at 12V input): <0.25A
8. Peak efficiency: >90%
9. Durative output power: 300W
11. Twinkling maximum power: 600W
12. Output waveform: Modified Modified Sine Wave
13) Hi-pot test: PRI/sec, 1500V/AC 5mA/60s
14) Temperature protection: 10°C-40°C
15) AC output short circuit protection: system shut down (no damage)
16) Fan run: Working with load
17) Fault warning: alarm beep
18) LED indicator:
a) Normal: green
b) Fault: red green
19) Environmental condition:
a) Operating temperature: -5~45°C
b) Operating relative humidity: 10-90% RH
c) Storage temperature: -10-50°C
d) Storage relative humidity: 10-95% RH
20. Size: 130*95*55(mm)
21. Weight: 690g
Regarding Auto power inverter and Electric-bicyle power inverter, besides 300w, we also have 80W, 100W, 150W, 500W, 800W, 1000W 1200W, 1500w
|
