Fuzhou Kejie Intelligent Technology Co., Ltd.
China Manufacturer with main products: PVC |
Digital Unmanned Automatic Truck Scales for 60t 80t 100t
| FOB Price: | 7900.00 - 8500.00 USD/Unit |
|---|---|
| Supply Ability: | 2,000 Unit(s) per Year |
| Shipping: | by sea |
| Payment Terms: | L/C, T/T |
Related products from verified members
| Export Markets: | North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe |
|---|---|
| Place of Origin: | Fujian in China |
| Packaging Details: | Platforms Are Packed by Film or Color Strip |
Quick Details
- Accuracy: OIML III
- Rated Load: 150%F.S
- Display Type: LED
- Type: Truck Scale
- Brand Name: Kejie
- Power Supply: 220v
- Model Number: SCS-60
- Structure: Electronic Scale
- Sensor: Digital Scale
- The Weighing Method: Static Truck Scale
- Operating Environment: Non Explosion-proof Loadometer
- Platform Size: 18x3m
- Scale Structure: U-Type Steel
- Lightning Protection: With Lightning Protection
- Division: 20kgs
- Surface Plate Thickness: 8+2mm Checkered Plate
- Port of Loading: Fuzhou, China
Specifications
Structure of truck scale platform (18x3m)
| Structure of truck scale | Modular steel structure |
| Dimension | 18x3m |
| Top plate | Checkered plate |
| Thickness of top plate | 8+2mm |
| Modules quantity | 10pcs |
| Bridge parts quantity | 6pcs |
| Dimension of long module | 5535x1500x320mm |
| Dimension of short module | 3695X1500X320mm |
| Weigh-bars | 4pcs |
| Dimension of each weigh-bars | 3000x350x300mm |
| U beam thickness | 6mm |
| U beam quantity | 8pcs |
| PlatformSize | Max capacity | Model | Division | Sections | Axle load | Net weight |
| 3X8m | 60t | SCS-MU-60T | 20kg | 2pcs | 15t | 4.5t |
| 3X10m | 60t | SCS-MU-60T | 20kg | 2pcs | 15t | 5.2t |
| 3X12m | 60t | SCS-MU-60T | 20kg | 2pcs | 15t | 5.9t |
| 3x14m | 60t | SCS-MU-60T | 20kg | 3pcs | 15t | 7.1t |
| 3x16m | 60t | SCS-MU-60T | 20kg | 3pcs | 15t | 7.8t |
| 3x18m | 60t | SCS-MU-60T | 20kg | 3pcs | 15t | 8.4t |
| 3X20m | 60t | SCS-MU-60T | 20kg | 4pcs | 15t | 9.7t |
| 3x22m | 60t | SCS-MU-60T | 20kg | 4pcs | 15t | 10.3t |
| 3x24m | 60t | SCS-MU-60T | 20kg | 4pcs | 15t | 10.9t |
Advantages of Kejie truck scale
1. Ideal delivery time
2. Fast and economical installation, even in restricted sites
3. Convenient access
4. No exposed wiring
5. Low profile
6. Full capacity test weights calibration for weighbridge before leaving factory
