Technical Parameters Of 165w Monocrystalline Solar Modules.
Model No.: GYS-165C(165W)
Origin(Country): China
Nominal Power Pmax(W): 165W
Tolerance(%): +/-5%
Kind of Cell(Mono. Poly): Mono
Cell per Module: 72(6X12)
Conversion Efficiency: ≥17%
Shape of cell "X” mm*mm: 125*125
Main Electrical Characteristics:
Voltage Mpp Vmp[V]: 34.5V
Current Mpp Imp[A]: 4.78A
Volt Open circuit Voc (V): 44.2V
Short out current Mpp Isc [A]: 5.18A
NOCT[C]: 47℃
Max system Volt[V]: 1000V
Dimensions(mm): 1580*808*50
Weight[kg]: ~16
Packing: 2pcs in one Carton
Guarantee of power %/Years: 80% of 20 years.
Guarantee on the whole product [years]: 2 years
Kind of glass and its thickness[mm]: 3.2mm
Number of Diods: 3
Type of diods: 10A
Conditions: (STD):
Temperature Coefficient Current Isc mA/℃: +0.08%℃
Temperature Coefficient Voltage Voc mV/℃: -0.37%℃
Temperature Coefficient Power Pmax/℃: -0.44%℃
Maximum Working Temperature: + 85°C
Minimum Working Temperature: - 40°C
Remarks:
1):185w Solar Panels with IEC Certificated.
2):By Pass Diodes inside ,with TUV Certificated.
3):All the Panels with Good quality and reasonable price.
| Place of Origin: | Shanghai in China |
| Model No: | GYS-165C(165W) |
| FOB Price: | 300-400 USD Shanghai |
| Payment Terms: | L/C,T/T(Bank Transfer), |
| Minimum Order: | Piece/Pieces 50 |
| Supply Ability: | Piece/Pieces|300|Day |
| Package: | 2 pcs in each Cartons |
| Delivery Time: | within 15-20days according to the order quantity |
