WQ SERIES SEWAGE SUBMERSIBLE PUMP

Capacity from 6 to 100m3/h
Power from 0.55 to 7.5 kw
Power supply from 220 to 380v
Frequency:50HZ
Pump medium is sewage which temperature is below 40 centigrade,PH value is between
6-8,contain solid granular and
sewage which can not dissolve in water should be below 20%(quality proportion)
Diametre is smaller than 3.5mm
MODEL        POWER     CAPACITY       HEAD
WQD6-10-0.55   0.55KW     6m3/h          10m
WQD7-11-0.75   0.75KW     7m3/h          11m
WQ8-16-1.1     1.1KW      8m3/h          16m
WQ15-26-2.2     2.2KW      15m3/h          26m
WQx12-50-4     4KW       12m3/h          50m
WQX-15-55-5.5    5.5KW      15m3/h          55m
WQ100-10-7.5    7.5KW      100m3/h         10m

Place of Origin:	Zhejiang Taizhou in China
Model No:	WQ
Brand Name:	JD
Package:	carton
