Motorcycle (BD150-20-IV)

Detailed Product Description

Dimension ((L*W*H)mm): 2090*825*1180
Wheel base (mm): 1350
Min. Ground Clearance (mm): 60
Dry Weght: 136kg
Maximum weight capacity: 160kg

Engine Type: Single-cylinder, air-cooled, four-stroke, 125cc or 150cc or 200cc
Engine model: 162FMJ
Bore*Stroke: 62mm*49. 5mm
Displacement: 149. 5mL
Maximum Power: 7. 8kW/rpm(8500+500 r/min)牋
Maximum Torque: 9. 8N. m/rpm(7000-500r/min)牋
Start: Electric start/Kick start
Max. Speed (km/h): 95km/h

Fuel tank Maximum capacity: 13L
Economical Fuel Consumption (l/100km): 2. 2L /100km
Front Type Size and Air Pressure: 100/80-18/225KPa
Rear Type Size and Air Pressure: 100/90-16/250Kpa
Front brake type: disk type
Rear brake type: rum type

Place of Origin:China|
Model No:BD150-20-I
Brand Name:Baodiao
