Scooter (BD50QT-2-V)

Detailed Product Description

BD50QT-2-V
(50CC or 125CC or 150CC)
Specification:
Dimension ((L x W x H) mm):1890x570x860
Wheel base (mm):1380
Min. Ground Clearance (mm):120
Dry Weight: 109kg
Maximum weight capacity: 150kg
Engine Type: Single-cylinder, air-cooled, four-stroke
Engine model: 157QMJ
Bore xStroke:57.4mm x 57.8mm
Displacement: 150mL
Maximum Power:7.0kW/rpm(7500+500r/min)
Maximum Torque:9.0N.m/rpm (7000-500r/min)
Lubrication: Pressure/splash
Start: Electric start/Kick start
Ignition: C.D.I
Max. Speed (km/h):85
Fuel tank Maximum capacity: 6L
Economical Fuel Consumption (1/100km):2.2L/100km
Front Type Size and Air Pressure: 130/60-13/225KPa
Rear Type Size and Air Pressure: 120/70-12/250KPa
Front brake type: disk type
Rear brake type: drum type
40' HQ:75 units
Place of Origin:Jiangsu in China
Model No:BD50QT-2-V
Brand Name:Baodiao
Payment Terms:L/C,T/T(Bank Transfer),
