Scooter (BD150T-15-N)

Detailed Product Description

* BD150T-15-N (125cc or 150cc or 250cc )
* Dimension ((L x W x H) mm): 2310 x 800 x 720
* Wheel base (mm): 1616
* Min. Ground clearance (mm): 145
* Dry weight: 175 kg
* Maximum weight capacity: 150 kg
* Engine type: single-cylinder, air-cooled, four-stroke
* Engine model: 157QMJ
* Bore x Stroke: 57.4 mm x 57.8 mm
* Displacement: 150ml
* Maximum power: 7.0 kw/rpm(7500+500r/min)
* Maximum torque: 9.0 N. M/rpm(7000-500r/min)
* Lubrication: pressure / splash
* Start: electric start / kick start
* Ignition: C.D.I
* Max. Speed (km/h): 80
* Fuel tank maximum capacity: 10.5 L
* Economical fuel consumption (i/100km): 2.2 l / 100 km
* Front type size and air pressure: 120/60-12/225kpa
* Rear type size and air pressure: 110/90-10/225kpa
* Front brake type: disk type
* Rear brake type: drum type
* 40' hq: 30 sets
Model No:BD150T-15-N
Brand Name:Baodiao
Payment Terms:L/C,T/T(Bank Transfer),
