Controls
* PLC
*Photo-eye auto-height sensing pallet height
*Separate top ,bottom & up-down Wrap Counter Selector
*Overwrap time is set to create an overwrap
*Reinforce wrap times is set to better secure 2 loads placed on top of each other
*Film Tension Control adjustment on the panel
*Separate start, pause and emergency stop buttons
*Power indicator
*Manual carriage up/down
*Variable Turntable Speed
*Carriage up/down speed control
*Manual/automatic eTurntable
*1650mm Diameter Structural steel plate
*85mm Height floor to top of turntable
Turntable drive
*0-12rpm variable turntable speed by frequency changer
*Position turntable alignment
*Soft start
Film carriage
*Powered pre-stretch system up to 200% to min film consumption
*Carriage door opens for effortless roll change and thread film
*Film delivery variable speed by separate DC Drive Motor
*Electronic film tension control adjustment on panel
*Film dancer-bar with variable speed output
Film carriage Drive
*Heavy duty double-chain carriage lift, calm and safety
*Film carriage variable speed by frequency changer
Option
*Ramp
*Top plate
*Auto film attach and cut off system
*Packing Height: 2400mm
*Turntable Diameter: 1800mm,2000mm
| Place of Origin: | Zhejiang Wenzhou in China |
| Model No: | T1650F |
| Brand Name: | DaJiang |
