Lens-adjustable TFT color LCD

Detailed Product Description

Release of New Product! You must not miss the chance of testing this innovative & unique design. You'll be surprised! The most accurate, specialized and efficient tool for your scheduling, design, installation, test and adjustment of CCTV construction. 1. With 3.5 TFT color LCD monitor 2. Built-in 1/3 color CCD camera 3. A device with turning wheel to adjust the lens. Built in five lenses (4 ,6, 8, 12 & 16mm) for selection. Easy operation on lens switch. Applicable for: Before design of CCTV- TFT-35CH provides multiple choices of the angles of view as well as confirmation on the selection of needed equipments, which avoids wasting unnecessary construction procedure and elevates the efficiency. After installation- TFT-35CH can test cameras' operating effect and precisely adjust the angles of view.

TFT-35CH LCD

1. 1/3” Panasonic D5 Color CCD Sensor

2. Number of Pixel: 512(H) x 492(V) ＜NTSC＞;512(H) x 582(V) ＜PAL＞

3. Resolution: 420 TV lines

4. Min. Illumination: 0.5Lux / F2.0

5. S/N Ratio: More than 48db(AGC off)

6. Electronic Shutter: 1/60(1/50) to 1/100,000 sec

7. Lens: Built in 4, 6, 8, 12, 16mm

8. The size of screen: 3.5” (Diagonal)

9.Pixel pitch:0.150mm(W)X0.216mm(H)

10.The effective display region:72mm(W)X50.544mm(H)

11.Input signal:1.0Vp-p Combination Video
