Components
Frame: Al Alloy 6061 T6
Tyres: 26"x1.75",puncture resistant K-shield
Rim: Al Alloy twin wall and CNC side wal
Spokes: 13g steel
Brakes(front): Disc-brakes
Brakes(Rear): V-brakes
Gears: 6-class Shimano(TX50)
Front fork:: Suspension,Al alloy double crown(ZOOM)
Handle bars: Al Alloy (ZOOM)
Head set:: Water proof headset
Chainguard: PC
Mudguard: Al alloy with Al alloy supports
Chainwheel : Steel 44 T,Al alloy crank
Chain: Rust resistant chain
BB: Cartridge type
Stander: Al alloy central stander
Rear carrier: Al alloy
Saddle : GEL Cruiser saddle
Seat Post : Al alloy with suspension(ZOOM)
Motor: 180-250w(EU)/350w(USA)High Speed Brush Gear DC hub motor
Option:High Speed Brushless Gear DC hub motor
PAS Controller: Inner Intelligent Torque Sensor PAS
Overload protection ,Low voltage protection
Battery : Option: 24V 8AH Ni-MH battery / 24V 8Ah or 24V 10Ah Li-ion battery
Charger : 220 / 110V, 50 - 60Hz 2 amps smart charger. Charge time 4-6 hours
Performance
Maximum Speed : ≤25Km/h
Range: 45-55km
Load capacity:: 125KG
Weight:: Ni-MH battery 3.7 kgs
Li-ion battery 2.8 kgs
N.W./G.W. : 26/30kgs
Carton Size : 1450x280x770mm
Capability : 96pcs/20' container 208pcs/40' HQ
| Model No: | TDF27Z |
| Package: | carton |
| Delivery Time: | 25 |
