Detailed Product Description
Components
Frame: Al Alloy 6061 T6
Tyres: 20"x1.95", puncture resistant K-shield
Rim: Al Alloy twin wall and CNC side wal
Spokes: 13g steel
Brakes(front): V-brakes
Brakes(Rear): V-brakes
Gears: 6-class Shimano(TX50)
Front fork: Suspension, Al alloy double crown(ZOOM) Handle bars: Al Alloy (ZOOM)
Head set: Water proof headset
Chainguard: PC
Mudguard: Al alloy with Al alloy supports
Chainwheel: Steel 44 T,Al alloy crank
Chain: Rust resistant chain
BB: Cartridge type
Stander: Al alloy central stander
Rear carrier: Al alloy
Saddle: GEL Cruiser saddle
Seat Post: Al alloy with suspension(ZOOM)
Motor: 180-250w High Speed Brush Gear DC hub motor
Option: High Speed Brushless Gear DC hub motor
PAS Controller: Inner Intelligent Torque Sensor PAS
Overload protection, Low voltage protection
Battery: Option: 24V 8AH Ni-MH battery / 24V 8Ah or 24V 10Ah Li-ion battery
Charger: 220 / 110V, 50 - 60Hz 2 amps smart charger. Charge time 4-6 hours
Performance
Maximum Speed: ≤25Km/h
Range: 45-55km
Load capacity: 125KG
Weight: Ni-MH battery 3.7 kgs
Li-ion battery 2.8 kgs
N.W./G.W.: 26/30kgs
Carton Size: 1400x280x640mm
Capability: 108pcs/20' container 261pcs/40' HQ
| Model No: | TDN24Z |
| Package: | carton |
