1) Components
* Frame: Al Alloy 6061 T6
* Tyres: 16"x1.95",puncture resistant K-shield
* Rim: Al Alloy twin wall and CNC side wal
* Spokes: 12g steel
* Brakes(front): V-brakes
* Brakes(Rear): V-brakes
* Gears: 6-class Shimano(TX50)
* Front fork:: Suspension,steel
* Handle bars: Al Alloy (ZOOM)
* Head set:: Water proof headset
* Chainguard: PC
* Mudguard: Al alloy with Al alloy supports
* Chainwheel : Steel 44 T,Al alloy crank
* Chain: Rust resistant chain
* Stander: steel stander
* Rear carrier: steel
* Saddle : Cruiser saddle
* Seat Post : Al alloy with suspension(ZOOM)
* Motor: 180-250w High Speed Brushless Gear DC hub motor
* Overload protection ,Low voltage protection
* Battery : Option: 24V 8AH Ni-MH battery / 24V 8Ah or 24V 10Ah Li-ion battery
* Charger : 220 / 110V, 50 - 60Hz 2 amps smart charger. Charge time 4-6 hours
2) Performance
* Maximum Speed : ≤25Km/h
* Range: 35km
* Load capacity:: 95KG
* Weight:: Ni-MH battery 3.7 kgs
* Li-ion battery 2.8 kgs
* N.W./G.W. : 22/25kgs
* Carton Size : 1400x280x640mm
* Capability : 108pcs/20' container 261pcs/40' HQ
| Place of Origin: | China| |
| Model No: | TDR32Z |
| Package: | carton |
