solar energy panel

The Flat-Plate system comprises an insulated, weatherproof box containing a dark
absorber plate under one or more transparent or translucent covers. Water or conducting
fluid passes through pipes located below the absorber plate. As the fluid
flows through the pipes it is heated. This collector, although inferior in many
ways to evacuated tube collectors, is still the most common type of collector
in African and some Asian countries.
Feature:
1.DIMENSIONS: 1975 x 975 mm
2.WEIGHT: 42 KGS
3.COLLECTOR: Closed circuit copper tube type
4.ABSORBER PIPING:
Vertical risers 12 mm (outside diameter) copper.
Horizontal headers 22mm (outside diameter) copper.
5.WORKING PRESSURE: 0.6Mbar
6.INSULATION: Polyurethane 20mm (40 kg/m3) cast under pressure.
Gives rigidity and humidity protection.
20mm Rockwool
7.CASING:
Aluminum profile epoxy powder oven painted
Free of screws and rivets.
Sea Water resistant.
8.GLASSING:
Tempered low iron glass 4 mm.
82% transmission.

Place of Origin:	Zhejiang jiaxing in China
Model No:	1250mm*1250mm
Brand Name:	tianxing
Other Price Terms:	250
Minimum Order:	1*20'
Supply Ability:	300000 sets
Delivery Time:	25
