| Video System |
NTSC / PAL (switchable) |
| Video Compression Format |
MPEG 4 |
| Video Input |
Composite video signal 1 Vp-p 75Ω BNC |
| Video Output |
Main Monitor Output: Composite video signal 1 Vp-p 75Ω BNC |
| |
Call Monitor Output: Composite video signal 1 Vp-p 75Ω BNC |
| Video Loop Out |
Composite video signal 1 Vp-p 75Ω BNC |
| Maximum Recording Rate |
Frame: 720 × 480 pixels with 120 IPS〈NTSC〉/ 720 × 576 pixels with 100 IPS〈PAL〉 |
| |
CIF: 352 × 240 pixels with 480 IPS〈NTSC〉/ 352 × 288 pixels with 400 IPS〈PAL〉 |
| Adjustable Recording Speed |
Frame: 120, 60, 30, 15 IPS / 100, 50, 25, 12 IPS |
| |
CIF: 480, 240, 120, 60 IPS / 400, 200, 100, 50 IPS |
| Image Quality Setting |
Best, High, Normal, and Basic |
| Hard Disk Storage |
IDE type, ATA66, supported HDD ＊ 1, support each HDD capacity over 750GB |
| HDD Quick Cleaning |
Quick clean up the "index system" of the recorded files. 750GB under 2 seconds |
| Recording Mode |
Manual / Timer / Motion / Alarm / Remote |
| Watermark |
Yes |
| Refresh Rate |
480 IPS for NTSC / 400 IPS for PAL |
| Multiplex Operation |
Live display, record, playback, backup and network |
| Audio I/O |
4 audio inputs, 2 audio outputs (Mono) |
| Motion Detection Area |
16 × 12 grids per camera for all channels |
| Motion Detect Sensitivity |
4 adjustable variable with precise calculation for motion detection |
| Pre-alarm Recording |
Yes (8 MB) |
| USB Interface |
Support USB 1.1/ 2.0 flash drives (front panel＊1, back panel＊1) |
| Backup Device |
USB1.1 / 2.0 flash drives backup and network remote backup |
| Web Transmitting Compression Format |
Motion JPEG |
| Ethernet |
10/100 Base-T. Support remote control and live view via Ethernet |
| Web Interface |
Support licensed software AP, and IE browser |
| Remote Alarm Notification |
E-mail images, and images uploading to FTP site's specific account |
| Network Protocol |
TCP/IP, PPPoE, DHCP and DDNS |
| Remote Control |
Remotely control DVR and PTZ cameras via IR transmitter (RS-485) |
| PTZ control |
Support PELCO-D protocol |
| Dwell Time (Sequential Channel Switch) |
Programmable with adjustable dwell time |
| Alarm I/O |
16 inputs, 1 output |
| Picture Zoom |
Support 2X digital zoom function |
| Key Lock |
Yes |
| Video Loss Detection |
Yes |
| Camera Title |
Support up to 6 letters |
| Video Adjustable |
Hue／Color／Contrast／ Brightness |
| Date Display Format |
YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off |
| Daylight Saving |
Yes |
| Power Source |
DC 19V |
| Power Consumption |
＜64 W |
| Operating Temperature |
10℃ ~ 40℃ (50℉~104℉) |
| Dimensions (mm) |
432mm (W) × 90mm (H) × 326mm (D) |
| System Recovery |
System auto recovery after power reconnected |
| Optional Peripherals |
Independent disk array; VGA converter |
| System Recovery |
System auto recovery after power reconnected |
| Optional Peripherals |
Independent disk array, VGA converter |
