Main Features:
* Built-in web server, allowing direct access to the Internet
* Built-in microphone
* PTZ control function
* Optical zooming 10x, 22x, etc. available, digital zooming 4x.
* Real time motion detection, e-mail notification and ftp images optional
* Double password protection
* Automatic network condition detection & adjustment
* Multi-window viewer software (IPS 16) available
* Surge protection (optional)
Specifications:
SYSTEM
Video compression
MPEG-4
Image resolutions
CCD ( Image sensor)
D1, NTSC: 720*480 @ 30fps; PAL: 720*576 @ 25fps
CIF, NTSC: 352*240 @ 30fps; PAL: 352*288 @ 25fps
CMOS ( Image sensor)
VGA, NTSC / PAL: 640*480 @ 30fps
QVGA, NTSC / PAL: 320*240 @ 30fps
Video adjustment
Brightness, Contrast, Saturation, Sharpness and Hue
Network Interface
Ethernet (10/100 Base-T)
Audio compression
G.711 PCM, 64Kbps; G.7126 ADPCM, 16-40Kbps
Multi-window display
Max. 16 videos (optional)
Protocols
ARP, TCP/IP, HTTP, FTP, SMTP, DHCP client, NTP, DDNS, UPnP, IEEE802.11b (optional)
System required
Microsoft IE 5.x or above running on Windows 2000/XP/2003
Firmware upgrade
HTTP online upgrade mode
MODEL
IPC 400P2
IPC 400P8
IPC 400S2
IPC 400S8
Image pick-up device
1/4" SHARP color CCD
1/3" SHARP color CCD
1/3" SONY color CCD
TV system
NTSC / PAL
Number of pixels
NTSC: 510(H)*492(V)
PAL: 500(H)*582(V)
NTSC: 768(H)*492(V)
PAL: 752(H)*582(V)
NTSC: 510(H)*492(V)
PAL: 500(H)*582(V)
NTSC: 768(H)*492(V)
PAL: 752(H)*582(V)
Horizontal resolution
420 TV lines
480 TV lines
420 TV lines
480 TV lines
Min. illumination
0.8 Lux / F 1.2
0.1 Lux / F 1.2
Scanning system
NTSC: 525 lines, 60 field / sec; PAL: 625 lines, 50 field / sec
Gamma characteristic
0.45
Electric shutter time
Auto, NTSC: 1/60~1/100,000 sec; PAL: 1/50~1/100,000 sec
S/N ration
> 48dB
Sync system
Internal synchronization
Video output
1Vp-p, 75 ohm
Power Supply
AC 24V/1000mA
Working Temperature
-10℃ ~ +50℃/RH 95% max
| Place of Origin: | Shenzhen in China |
| Model No: | IPC400 |
| Brand Name: | telebahn |
