wireless spy camera watch with DVR(TE-828)

Detailed Product Description

*Wireless transmission provides real time video on DVR to view effect as you record;
*Small size of transmission camera hides into a normal working watch;
* Near and far focus available for choice (near focus for small text record);
*3.5"TFT LCD screen with up to 800X600 resolution;
*Video Format: Mpeg-4,AVI (800 or 320 @ 30fps) MP4,3GP;
*Memory: built-in flash :2GB~8GB; support SD card 1GB to 16GB;
*380TV line for clear image;
*4 channels available to avoid possible interference;
*Built-in antenna and rechargeable Li-battery;
*100m transmission distance without blocks
Specification:

 Transmission Frequency
 ISM 2,400MHz~ 2,483MHz    4CH*
 Modulation Mode
 FM
 Antenna Type
 Hidden
 Unobstructed Effective Range
  100m(Without Block)
 Operating Temperature
 0℃~ +50℃ / +14℉~ +122℉
 Storage Temperature
 -20℃ ~ +60℃ / -4℉ ~ +140℉
 Operating Humidity
 85%RH
 CAMERA
 Imaging Sensor Type
 CMOS
 CMOS Total Pixels
 510×492(NTSC)
 Horizontal Resolution
 380 TV Lines
 View Angle
 62°
Camera lens focus
Beyond:3m vicinity:10cm
 Minimum Illumination
  3.0 Lux / F1.5
 Transmission Power
 10mW
 Power Supply
 DC 5V 95mA
 Battery Performance
  Li-ion Battery
 Battery Capacityl
  130 mAh
Charge time
30 minutes
 Working Time
 1 hour
Dimensions( HX D)
18mm*48mm
 Weight
  50g
 RECEIVER
Receiving CH
CH1~CH4
Sensitivity
-92dB
LCD
3.5 inches TFT
AV out
NTSC / PAL
Resolution
640*480 / 320*240
Video compress
MPEG-AVI    30fps
Play format
RM / RMVB / 3GP / MP4 / FLV / AVI / ASF / WMV / DAT / VOB / MPG
Frequency
20HZ-20KHz  stereo
Earphone Output
Left: 20MW+ right 20mW [16O](suit to largest volume)
Play format
MP3 / WMA / AMR / AAC / FLAC / APE
Speaker
0.6W
File format
JPG/JPEG
FLASH
2GB-8GB (default 2GB)
Outer SD card
TF card 1GB-16GB( optional purchase)
IBM-PC
Windows 2000、XP & VISTA
Port
HI-USB 2.0
Language
Multiple languages
AC adapter
DC 5V 2A
Built-in battery
Li-battery 1200Mah
Wireless record
≥2.5 hours
Video record
≥5 hours

Place of Origin:Shenzhen in China
Model No:TE-828
Other Price Terms:FOB shenzhen
Payment Terms:T/T(Bank Transfer),Western Union,PayPal,
Minimum Order:Set/Sets 1
Supply Ability:Set/Sets|2000|Month
Package:1set/paper box;1.5kgs/set
Delivery Time:sample are ready
