Refrigeration Compressed Air Dryer

Features:
1) Low running cost,low pressure drop and steady dew point
2) Easy to install and maintain
3) Ideal for high environmental temperature
4) Microprocessor control
5) Suitable for a range of air compressors
6) Includes:
a.Air to air heat exchanger
b. Evaporator
c.Refrigerant compressor
d. Hot gas bypass valve
e.Expansion valve
f. Water separator
g.Condenser
h. Automatic drain
i. Pressure control for compressor
j. Condensing pressure regulator(water valve)
k. Pre-cooler
7)Custom designs welcome
Specifications:
1)Pressure dew point:2-10 oC (designed PDP:1.7oC)
2)Rated operation pressure:0.6 - 0.95Mpa
3)Inlet air temperature:≤45'C(≤55'C and ≤80oC optional)
4)Ambient temperature:2 - 38oC(only for air cooling)
5)Cooling water temperature:2 - 35oC(only for water cooling)
6) Pressure drop:0.015Mpa(working pressure:0.7Mpa)

Place of Origin:	Zhejiang Hangzhou in China
Model No:	RSL Series
Brand Name:	Risheng
