The adsorption priniple used in this design is simple,robust and flexible.Continuous drying is accomplished by the operation of 2 desiccant pressed air is dried through one tower while the other desiccant tower is being regenerated.The regeneration heating cycle of the desiccant is accomplished using a dry air purge flow heated by an external electric heater.The regeneration cooling cycle is performed using the same flow of dry compressed air taken from the dryer outlet to ensure accurate dew point performance.
By using proven engineering technology and components,this equipment is extremely reliable.
Features:
1) Low running cost,low pressure drop and steady dew point
2) Easy to install and maintain
3) Ideal for high environmental temperature
4) Microprocessor control
5) Suitable for a range of air compressors
6) Custom designs welcome
Specifications:
1)Constant pressure dew point:-20'C,-40'C
2)Rated operation pressure:0.6 - 0.95Mpa(g)
3)Regenerative consumption:<14%
4)Inlet air temperature:≤40'C
5)Desiccant:activated aluminum oxide or molecular sieve
6)Power supply:220V AC,50Hz
7) Pressure drop:≤0.02Mpa(working pressure:≤0.7Mpa)
8)Fully automatic,interlocked operation controlled by PLC on a fixed 10min time cycle
9)End connection/flange:JB/T81
| Place of Origin: | Zhejiang Hangzhou in China |
| Model No: | RSXW |
| Brand Name: | Risheng |
