Excavator

Power/speed 16KW/2200rpm
Operating weight 1.76t
Bucket capacity 0.04-0.1m3
Bucket digging force 11.44kn
Arm digging force 8.04kn
Pressure of Hydraulic system 16mpa
Hydraulic pump 10+10 (ml/r)
Swing Speed 10.6rpm
Traveling speed 2.25km
Tracking force 11.54kn
Gradeability 30 degree
Ground pressure 23 kpa
Swing angle of arm Left 65/right 52
Undercarriage Width 1050
Center clearance between tracks 850
Undercarriage Width 1080
Length on the ground 1260
Dozer height 242
Dozer width 1100
Dozer lifting height 210
Dozer cutting depth 192
Rear swing radius 1200
overall length for transportation 3760
Overall height 2250
Clearance under upperstructure 467
Clearance under engine cover 1297
Front swing radius 1612
Track width 230

Place of Origin:	Shandong Weifang in China
Model No:	mini CT 18-7
Brand Name:	Sinomachine
