1. engine type :50cc/70cc/90cc/110cc,4 storke
2. bore and stroke :39x41.4/47x41.4/47x49.5/52.4x49.5
3. compression rating :8.8:1
4. max torque :4.2Nm/5000rpm , 4.2Nm/5000rpm, 5.2Nm/5000rpm, 5.5Nm/5000rpm
5. max power :3.0Kw/8500rpm/ ,3.0kw/7500rpm,3.3kw/7500rpm,3.6kw/7500rpm,
6. ignition type :CDI
7. transmission :automatic/(4-speed,semi-automatic),chain
8.Brake (Front/Rear):No/Disc
9. starting system :Electric start
10. battery spec :12V,4AH
11. front suspension details :double A x swing arm
12. rear suspension details :mono shock swing arm
13. front tire spec : 16X8-7
14. rear tires spec : 16X8-7
15. vehicle dimensions :138x75x90cm
16. wheel base :880mm
17. seat height from ground :60cm
18. ground clearance :100mm
19. load capacity :75kg
20. fuel tank capacity :3.2L
21. gross weight in carton :94kg
22. net weight :78kg
23. packing size:132x76x62cm
Conveyance:
Qty/20' GP:38 units
Qty/40' GP: 76 units
Qty/40' HQ: 108 units
| Place of Origin: | Zhejiang in China |
| Model No: | JLA-04 |
| Brand Name: | JinLing |
| CHINA ATV: | 50CC ATV |
