1. Engine type :200cc/250cc,4 storke,Water / Air Cooled.
2. Bore and stroke 63.5x62.2/72x62.2
3. Compression rating :9.2:1
4. Max torque : 13.5Nm/5500rpm, 17.5Nm/5000rpm
5. Max power :10kw/7500rpm,11kw/7500rpm
6. Ignition type :CDI
7. Transmission :manual clutch,4-speed,reverse gear,chain
8.Brake (Front/Rear):Drum or Disc /Disc
9. Starting system :Electric start
10. Battery spec :12V,9AH
11. Front suspension details :double A x swing arm,:air chamber shock absorbers
12. Rear suspension details :mono shock swing arm
13. Front tire spec : 19x7-8
14. Rear tires spec : 18x9.5-8
15. Vehicle dimensions :155x81x100cm
16. Wheel base :1000mm
17. Seat height from ground :75cm
18. Ground clearance :100mm
19. Load capacity :150kg
20. Fuel tank capacity :4.5L
21. Gross weight in carton :160kg
22. Net weight :140kg
23. Packing size:147x83x77cm 33pcs/20ft 66pcs/40ft 66pcs/40'HQ
| Place of Origin: | Zhejiang in China |
| Model No: | ATV200B |
