300CC new ATV

ENGINE TYPE: Single cylinder 4 Stroke Water cooled, CVT
DISPLACEMENT: 276CC
Bore * Stroke: 72.5mm*66.8mm
MAX. POWER (KW/rpm): 13.5kw/6000r/min
MAX. TORQUE (Nm/rpm): xxxxx/5000r/min
MAX. SPEED: 70km/h
Clutch: auto
WHEELBASE (mm): 1271mm
SEAT HEIGHT (mm): 895mm
GROUND CLEARANCE: 183mm
NET WEIGHT (kgs/lbs): 267kgs
COMPRESSION RATI 10.3:1
CARBURETOR: CVK052
LUBRICATE: Seperated&pressure
AIR FILTER TYPE: Dry Air filter Net
SPARK PLUG: A7RTC
STARTING: xxxxx Electric
GEARSHIFT: Forward (H/M/L) and Return
TRANSMISSION: Shaft
BRAKE FRONT: Front double hydraulic disc brake
BRAKE REAR: Rear double hydraulic disc brake
BRAKE DISTANCE: <=15m
FRONT SUSPENSION : Double Wishbone
REAR SUSPENSION : Single Wishbone
SHOCK ABSORBER (F): Double Wishbone
SHOCK ABSORBER (R): Single Wishbone
BATTERY: 12V-14AH
LUBR. CAPACITY: 1.6L
FUEL: 93#
FUEL CAPACITY : 14.5L
TURNING RADIUS: 3280mm
MAX. LOAD (kgs/lbs): 156kgs
FRONT TIRE: 25*8-12
REAR TIRE : 25*10-12
OVERALL (L/W/H): 2016*1180*1237mm
CARTONE SIZE (L/W/H): 2280*1290*870mm
PACKAGE 20"/40" (SET): 8pcs/27pcs

Place of Origin:	Zhejiang in China
Model No:	FA-D300
Brand Name:	BUYANG
Payment Terms:	L/C,T/T(Bank Transfer),
