Detailed Product Description
DLX-DVOP4 product is a fiber optic digital multiplexer for transmitting 4 channels of high quality, uncompressed digital video, 1channels of bi-directional data over a single fiber cable. Applications for this product include CCTV, video surveillance, homeland security, its and etc.
Video interface: 4 channels
1. Input / output impedance: BNC 75ohm unbalanced connector
2. Input / output voltage: typical peak value 1vp-p, up to 1. 5vp-p
3. Format: PAL / NTSC / secam
4. Bandwidth: 8mhz
5. Digitization: 8bits / 10bits / 12bits
6. Dg <0. 7%
7. Dp 8. Snr >66db
9. Connectors: BNC
Data
1. Rs485 date rate: 0-115. 2kbps
2. Supports rs485 transparence protocol
3. Error code rate: <10~9
4. Connector: rj45
Fiber connector
1. Connector type: fc / PC
2. Fiber type: single-mode, single-fiber
3. Transmission distance: 25km
Environment
1. Operating: -30 c~ + 75 c
2. Storage: -45c ~ + 85c
3. Humidity: 0-95% non-condensing
4. Input voltage: AC 220v, DC-48v, + 24v, + 12v, + 5v
5. Power consumption: below 5w (single-end)
| Place of Origin: | Shenzhen in China |
| Brand Name: | DLX |
| Delivery Time: | 3days |
