DLX-860 Managed Fiber Media Converter includes one Chassis, one managed main control card and one managed operation card. This converter adopts 2U standard height and contains 17 slots, 16 pieces different kind of DLX-860KM series line card and one piece DLX-860N managed card can be inserted into one rack. It supports loop back and network management of diagnostic test button, maintenance and centralized access to MDU functions, supports network management graphical and command line mode of out-of-band management based on SNMP, Telnet and Web as has a suit of advanced EMS network software. Rate, duplex, temperature, power type, output voltage, status of ports, fan speed etc. can be set and monitored. Besides, It supports alarm record saved and printed function.
Product Feature
Supports management based on SNMP, Telnet, Web mode and local RS-232 port
Supports SNMP v1/v2
Supports renovate system function, supports system auto refresh regularly via set time, protect from system halted
The network management system can be stacked up to 32 systems for the sake of economize IP address
Supports bandwidth options control on each port in the form of 1/4 rate, 1/2 rate, 3/4 rate and full rate
Each electrical port can be configured to 10M, 100M, full-duplex and half-duplex via network management
Each optical port can be configured to 100Mbps and full-duplex
Detect and control the operational states of electrical port and optical port of the near end and the far end via interface of management
Supports legal maximum packet size up to 1912 bytes, support CISCO, ISL and VTP
Supports open or close electrical and optical ports through via the far end network management
Each rack can be alone managed via WEB, Telnet as well as can be centralized managed via SNMP
Supports node auto-search and manual search function
Supports date copy and resume and has inquire and record log function
Support the statistic of date packets and supply necessary date for charge of bandwidth
Supports LLD, LLR and LLCF function
Each converter supports hot insert and pull and supports plug and play function
Operation mode of Media Converter module can be set, remote restart can be supported
Supports port flag
Supports remote port management function, optical link-loss alarm and remote diagnostic functions
Supports set IP to manage network system and different ranks network functions
16 pieces optical converter card can be inserted into one rack
Technologies reference
Operating temperature: 0-50
Storage temperature: -40-70
Environment humidity: 5-90%(non-condensing)
| Place of Origin: | Shenzhen in China |
| Delivery Time: | 3days |
