CCTV Camera (TT-SO32BW)

CCTV Camera (TT-SO32BW)

Contact Now

Detailed Product Description

Major Features:

　

B/W 1/3 SONY SUPER HAD CCD 420TVL

0. 5 Lux 3. 6mm board lens included CS mount selectable 38 x 38mm or 32 x 32mm selectable. PAL/NTSC

Stable Performance

Product Specifications:

　

　

Model	TT-SO32BW
Image Sensor	B/W 1/3 SONY SUPER HAD CCD
TV system	PAL/ NTSC
Effective Pixels	512X 582 Pixels/512X 492 Pixels
Resolution	420 TV Lines
Horizontal Sync. Frequency	15. 625KHz/15. 734KHz
Vertical Sync. Frequency	50Hz/60Hz
Min illumination	0. 5Lux
Video Output	BNC 1. 0Vp-p 75ohm
S/N Ratio	≥48dB(AGC Off)
Electronic Shutter Time	PAL = 1/50 - 1/100, 000 seconds NTSC = 1/60 - 1/100, 000 seconds
Power supply	12V DC
Operation Temperature	-10 to 50 deg. C (Humidity: 95% max)
Storage Temperature	-20 to 60 deg. C (Humidity: 95% max)

Place of Origin:	Shenzhen in China
Model No:	TT-SO32BW
Brand Name:	TT
Payment Terms:	L/C,T/T(Bank Transfer),Western Union,PayPal,
Supply Ability:	Piece/Pieces\|200000\|Month
Package:	RETAIL BOX
Delivery Time:	7-15 DAYS
