Model No.
.
Item |
FTL-S3306H+ |
FTL-S2506H+ |
FTL-S2006H+ |
FTL-S1606H+ |
|
Technology |
Drop-on-demand Piezo electric |
Drop-on-demand Piezo electric |
Drop-on-demand Piezo electric |
Drop-on-demand Piezo electric |
|
print head |
6 pieces (Seiko/spt255) |
6 pieces (Seiko/spt255) |
6 pieces (Seiko/spt255) |
4 pieces (Seiko/spt255) |
|
printing width |
3.2m wide |
2.5m wide |
2.05m wide |
1.6m wide |
|
Resolution |
1440dpi Max |
1440dpi Max |
1440dpi Max |
1440dpi Max |
|
Speed |
2pass 36㎡/h |
2pass 32㎡/h |
2pass 28㎡/h |
2pass 28㎡/h |
|
3pass 28㎡/h |
3pass 24㎡/h |
3pass 20㎡/h |
3pass 20㎡/h |
|
4pass 22㎡/h |
4pass 18㎡/h |
4pass 16㎡16/h |
4pass 16㎡/h |
|
6pass16㎡/h |
6pass 12㎡/h |
6pass 10㎡/h |
6pass 10㎡/h |
|
8pass 12㎡/h |
8pass 8㎡/h |
8pass 6㎡/h |
8pass 6㎡/h |
|
Locating Mode |
Raster/Servo |
Raster/Servo |
Raster/Servo |
Raster/Servo |
|
Color |
CMYK LM LC |
CMYK LC LM |
CMYK LM LC |
CMYK LC LM |
|
Media width |
3.2m |
2.5m |
2.0m |
1.6m |
|
Media Handling |
Roll to roll |
Roll to roll |
Roll to roll |
Roll to roll |
|
Media Types |
Flex banner ,PVC, mesh fabrics,
vinyl sheet, carpet Paper |
Flex banner ,PVC, mesh fabrics,
vinyl sheet, carpet Paper |
Flex banner ,PVC, mesh fabrics,
vinyl sheet, carpet Paper |
Flex banner ,PVC, mesh fabrics,
vinyl sheet, carpet Paper |
|
Ink Characteristics |
Solvent-base pigments,
two-year outdoor life |
Solvent-base pigments,
two-year outdoor life |
Solvent-base pigments,
two-year outdoor life |
Solvent-base pigments,
two-year outdoor life |
|
File format |
TIFF,RGB and CMYK |
TIFF,RGB and CMYK |
TIFF,RGB and CMYK |
TIFF,RGB and CMYK |
|
Working Process |
Maintop software for
printing(window 98,XP) |
Maintop software for
printing(window 98,XP) |
Maintop software for
printing(window98, XP) |
Maintop software for
printing(window98, XP) |
|
Dimesion |
4.6mx0.8mx1.3m |
3.8mx0.8mx1.3m |
3.3mx0.7mx1.3m |
2.9mx0.7mx1.3m |
|
Power supply |
50Hz/60Hz, 220V(±10%)>15A |
50Hz/60Hz, 220V(±10%)>15A |
50Hz/60Hz, 220V(±10%)>15A |
50Hz/60Hz, 220V(±10%)>15A |
|
Operation Environment |
Temperature 18C-26C
Relative Humidity 40-70% |
Temperature 18C-26C Relative
Humidity 40-70% |
Temperature 18C-26C Relative
Humidity 40-70% |
Temperature 18C-26C
Relative Humidity 40-70% |
|
Weight |
600kg |
500kg |
400kg |
350kg |
