large format solvent printer

Detailed Product Description

Model No. Item	FTL-S5304	FTL-S5306+	FTL-S5312+
Technology	Drop-on-demand Piezo electric	Drop-on-demand Piezo electric	Drop-on-demand Piezo electric
print head	4 pieces (Seiko/spt510)	6pieces (Seiko/spt510)	12 pieces (Seiko/spt510)
printing width	5.0m wide	5.0m wide	5.0m wide
Resolution	1440dpi Max	1440dpi Max	1440dpi Max
Speed	2pass88㎡/h	2pass 90 ㎡/h	2pass 98㎡/h
	3pass 63㎡/h	3pass 60㎡/h	3pass 72㎡/h
	4pass 54㎡/h	4pass 48㎡/h	4pass 54㎡/h
	6pass 43㎡/h	6pass 36㎡/h	6pass 36㎡/h
	8pass 27㎡/h	8pass 29㎡/h	8pass 26㎡/h
Locating Mode	Raster/Servo	Raster/Servo	Raster/Servo
Color	CMYK	CMYK LC LM	CMYK LC LM
Media width	5.2m	5.2m	5.2m
Media Handling	Roll to roll	Roll to roll	Roll to roll
Media Types	Flex banner, PVC, mesh, fabrics vinyl sheet, carpet paper	Flex banner, PVC, mesh, fabrics vinyl sheet, carpet paper	Flex banner, PVC, mesh, fabrics vinyl sheet, carpet paper
Ink Characteristics	Solvent-base pigments, two-year outdoor life	Solvent-base pigments, two-year outdoor life	Solvent-base pigments, two-year outdoor life
File format	TIFF,RGB and CMYK	TIFF,RGB and CMYK	TIFF,RGB and CMYK
Working Process	Maintop software for printing(window 98,XP)	Maintop software for printing(window 98,XP	Maintop software for printing(window 98,XP
Dimesion	7.2mx1.4mx1.7m	7.2mx1.4mx1.7m	7.2mx1.4mx1.7m
Power supply	50Hz/60Hz, 220V(±10%)>15A	50Hz/60Hz, 220V(±10%)>15A	50Hz/60Hz, 220V(±10%)>15A
Operation Environment	Temperature 18C-26C Relative Humidity 40-70%	Temperature 18C-26C Relative Humidity 40-70%	Temperature 18C-26C Relative Humidity 40-70%
Weight	3000kg	3000kg	3000kg
