ATV (XY-ATV250G)

250cc/200cc/150cc off road ATV
Engine : 250 CC ,Cylinder, 4-stroke, Water -cooled
low gas consuming : 3.5L/100km
Lubrication oil : SE15W/40
Spark plug : D8RTC
Compression ratio: 9.2:1
Max power (Kw/min): 11.5Kw/7500 r/min
Max torque (Nm/min): 17.5N.m/6000r/ min
Bore*stroke (mm*mm): 67*65mm
Transmission : 4- speed + reverse , not circle .
Ignition: C.D.I Starting: Electric
Lubrication: Pressure & Spray
Parking brake: Rear wheel
Battery : 12V-9AH
Carburetor size ; PZ30
Fuel capacity (liter/gallons): 5.5/1.36
front light: 12V35W/35
Clutch : manual clutch
Dry weight : 181KG
Loading weight : 160kg
Max speed : >= 83 km/h
F/R brake: Dual /single disc , the front brake is separated with the rear brake
Wheel rim : steel
Final drive : Chain
Front/ Rear independent suspension : Dual A-arm/Swing arm , both front and rear are air big shock .
Front/Rear tire : 23×7-10/22×10-10
Productsize : 2060*1210*1230mm
Carton size : 2200*1170*880mm,
Gross /Net weight : 306/260kg
