ZXG-12C Linear Filling Machine

The machine is controlled by PLC with a 5.7 inch touch screen. It adopts fixed flowing parameter with normal pressure and finishes different volume filling by controlling filling time. The machine with a simple structure, can be used for any size bottles and adjust it without changing any parts. It is suitable for high quality filling such as milk-oil and water.

Technical Parameter:

Type: ZXG-12C

Bottleneck: min.33mm max.100mm

Measure Accuracy: About 1%

Filling Volume: mim.40ml max.1000ml

Production Ability: 5400 bottles/h

Air Pressure: 0.5~0.7 Mpa

Air Waste: 200L/min

Power Supply: 380V /50Hz

Total Power: 0.5 KW

Dimension: (L) 2000mm (W) 800mm (H) 2600mm

Weight: 550KG
