1. It has special ‘L’ work arm which is good for operate on sleeves, trousers parts
2. It makes the system be very high to circulate speed and strong calculation function by
adopting 32 ARM processor as its CPU.
3. emperature automatic controlled by PLC, and fire alarm system to protect heater
element.
4. Aumatic controlled PLC for circuit, high precision for working.
5. speed digital setting 0～28m, precision is □0.03mm/s.
6. Hot air from nozzle automatic adjustable avoids fabric burn, fit for different thickness fabric.
7. Single air blow supply air for heating system avoids compressed vapor and oil.
8. Automatic tape cutting, sending and sealing trail to minimize waste of tape material.
9. Automatic mini back function for better product quality.
Parameter:
Power supply: 220V
Power: 2KVA
Compressed air: 3Kg/cm
Rubber roller re: 5-30m/min
Heating power: 1800w
Heating temperature: 0-750
Rubber roller width: 25mm standard
Fusible band width: 14~23mm
Upper roller lift: 30mm
| Place of Origin: | Shanghai in China |
| Model No: | QG-7700 |
| Brand Name: | QG |
| Payment Terms: | T/T(Bank Transfer), |
