Wheel Loader (SWL75F)

  Model : SWL75F
  Bucket capacity:  4. 2m3
  Wheel base:  3400 mm
  Tread : 2350 mm
  Min. ground clearance:  510 mm
  Rated load : 7500kg
  Max. breakout force : 220Kn
  Dump reach:  1275 mm
  Digging depth : 221 mm
  Min. turning radius:  6487 / 7042 mm
  Lifting time of bucket:  6. 1s
  Lowering time of bucket : 3. 8s
  Dumping time:  1. 9s
  Max. travel speed : 37km/h
  Engine:  Cummins M11-C
  Rated power : 216kw/2100 rpm
  Gear box:  ZF
  Fuel tank capacity:  423L
  Hydraulic oil tack: capacity  300L
  Operation weight: 23500 kg
  Overall dimension: 8698 x 3099 x 3686 mm

Place of Origin:	Shanghai in China
Model No:	SWL75F
Brand Name:	Sinoway
Payment Terms:	L/C,T/T(Bank Transfer),
Minimum Order:	Set/Sets 1
Delivery Time:	30 days
