Sinoway Grabbing Crane ( QLYS-20L)

Prev Product

Next Product

Detailed Product Description

Quality parameter
Driving state quality	27400kg
quality	28300kg
Wheel loading
Front wheel loading	14500kg
Rear wheel loading	12900kg
Driving parameter
Max.driving speed（Internal Combustion engie）	15km/h
Min.turning radius	8m
Min.earth clearance	0.25m
Parameter full crane
Full length	6.5m
Full width	3.1m
Full height	3.1m
Boom length（main boom Vice boom）	10~26m
Max.Hoisting height	25m
Wheelbase	3.2m
Wheelbase
Real wheel	2.3m
Front wheel	2.3m
Motivate parmeter
Tyre specification	12.00-20
Electromator
Power	45kW
Type	YB225M—4
Internal Combustion engie
Power	105kW
Type	YC6108ZG
Technical parameter of driving state
Main parameter
Max.Rated hoisting weight	20t
Min.Rated amplitude	3m
Max.hoisting torque	600kN.m
Max.Hoisting height
Basic boom	10m
longest main boom	25m
Outrigger distance
longitude	5.6m
Cross direction	5.4m
Max.angle of atitude	78°
Min.angle of atitude	-1°
Working speed
Max.steering speed	3.1r/min
Amplitude time
Fully raising boom	≥50s
Fully falling boom	≥50s
Lifting speed
Couple pump	≥95m/min
Outrigger extending and retracting time
Extending simultaniously (Horizon)	≤21s
Retracting Simultaniously (Horizon)	≤16s
Extending simultaniously (Vertical)	≤25s
Retracting Simultaniously (Vertical)	≤21s
Drving speed
Electromator	0~5km/h
Internal Combustion engie	0~15km/h
