Detailed Product Description
Dimension (LxWxH):2000x1270x1180mm
Wheelbase: 1320mm
Distance between front wheels:920mm
Distance between rear wheels:935mm
Ground clearance: 280mm
Gross Weight: 320kg
Fuel tank: 13L
Max. speed: 75km/h
Brake system: Front: Dual hydraulic discs with 2-piston calipers
Rear: Hydraulic disc with 2-piston calipers.
Suspension(F/R): Independent dual A-arm.
Transmission: Electric shift with 5 gears.
Transmission mode: Shaft
Drive system: 4WD,2WD transfer 4WD is available.
Tire front: 25x8-12
Tire rear: 25x10-12
Cargo front: 66lbs (30kg)
Cargo rear:133lbs (60kg)
Tow weight limit: 3376N (385kgf/850lbs)
Tongue weight: 137N (14kgf/30bs)
Engine
Engine model:179F
Efficient Capacity:359ml
Compression Ratio:8.8:1
Engine type:4-stroke, Single-Cylinder
Cooling system: Oil-cooling
Rated power and rotate speed :12kw/5200rpm
Max torque and rotate speed :23N.m/4000rpm
Economical oil consumption (L/100km):≤7
Carburetion: Carburetor (KEIHEN)
Electrical Battery:12V-14Ah
Starting system: Electric/Hand-pull
Ignition: DCDI
Bore X Stroke: 78.5mm X 74.2mm.
Loading quantity:
10pcs/20' GP, 22pcs/40' GP, 34pcs/40' HQ
| Place of Origin: | Guangdong in China |
| Model No: | TT-ATV400E |
| Brand Name: | TOPTOM |
| Payment Terms: | L/C,T/T(Bank Transfer),D/A,Western Union, |
