Detailed Product Description
Features:
. SDI and analog composite PAL/NTSC video input
. MPEG-2 MP@ML video encoding 1.5 to 20 Mbit/s
. SDI de-embedding of 1 audio group
. 1 stereo paris as standard(2*XLR analog audio inputs)
. MPEG II LayerI/II audio encoding
. 2*ASI outputs
. 4*E1 option outputs
. SNMP Support
INPUTS
Video SDI serial digital video
Analogue composite video(PAL/NTSC)
SDI component 625 and 525 line standard supported
Audio 1 stereo pair input via analogue,AES-EBU or SDI
Analogue audio balanced 75 Ω
1 stereo pair can be de-embedded from SDI
OUTPUTS
2 ASI copper Single Program Transport Stream
OPTION
4*E1 outputs
VIDEO ENCODER
MPEG-2 4:2:0 MP@ML 1.5 to 20Mbit/s
AUDIO ENCODER
1*stereo audio channel processing
MPEG Layer II audio encoding standard
encoding rates from 16kps to 512kbps
CONTROL
Front panel LCD with quick access keys
NMDVS supported via dual Ethernet
Support for external SNMP control
PHYSICAL AND POWER
Dimensions(w*d*h): 48.3*35.0*4.4cm(19'*13.8'*1RU)
Approx Weight: 6kg
Power Input: 220-240 Vac
Consumption: 15W maximum
Cooling: radiator
ENVIRONMENTAL CONDITIONS
Operating Temperature: 0癈 to 60癈(32癋 to 140癋)
| Place of Origin: | SICHUAN CHENGDU in China |
| Model No: | TELE-E |
| Brand Name: | TELE |
