Soft Ice Cream Machines (225A)

Table model
Air cooling
Twin twist flavours
Air pump  freezer

Voltage: 220V/50HZ/1PH
Power: 2.4KW
Capacity(Liters/Hr): 25
Dimension(mm) (NET): 550/650/960
Dimension(mm) (PACKING): 650/780/1160
N. W. (Kg): 160
G. W. (Kg): 180

 Packing: Carton With Pallet
Loaded In 20 Container: 54units
Loaded In 40 Container: 108units

Specifications:
Freezing Cylinder: 2x1.7Liter
Mix Hopper: 2x12.5Liter
Separate hopper refrigeration(S. H. R. )maintains mix below 5centigrade temperature
Refrigeration System
Main refrigeration:
One compressors: 3650BTU/hr. R404a
Separate hopper refrigeration(S. H. R)
One compressor: 420BTU/hr. R134a(BTU may vary depending on compressor used)
Beater Motor: One, 2.0HP
Capacity: 190 Cones/Hour(100g/Cone)(Capacity varies depending on condition of mix and environment)

Options:
Manufactured upon request, not available in stock
Power supply 220V/60HZ/1PH. Or 220V/60HZ/3PH
Local specific plugs of power supply wire
Special Packing Dimension
Ice cream cone dispenser
Cover of dispenser doorFeatures
Offer all popular soft ice serve variations from low or non-fat ice cream to custards, yogurt sorbet.

Standby
During long no-use periods, the standby feature maintains safe product temperature in the mix hoppers and freezer cylinders.

Electronic controls
The microprocessor controls that regulates refrigeration by measuring product viscosity to maintain consistent quality.

Hardness digital indicator
The product viscosity is displayed to assure safe product.(Excluding model 218)

Safety
Separate overload protections are inside motor and compressor. And thermal overload relay is for whole machine.

Air pump (Model number with letter A)
Grind mix with more air to a softer and smoother product, more overrun

Refrigeration parts
Compressor : ASPERA and MANEUROP DANFOSS
Refrigerant : R404a and R134a
Expand valve: DANFOSS
Condenser: Internal thread copper pipe

Electronic parts
SCHNEIDER ELECTRIC a??TELEMECANIQUEa??

Freezing cylinder
No welding line, hard-drawn from mould, hygeian standard, AISI 304 stainless steel, refrigerant contacts directly wall of cylinder without wrap pipes.

Mix hopper
Separate hopper refrigeration (xxxxx) with separate compressor to pre-cool mix and maintain mix below 5
