pen plotter
Plotter Features: More Stylish and StableMore streamline appearance makes a better look, and newer metal materials in the plotter head can avoid the static when the plotter is working. More AffordableProvide you a wide selection of pen types i.e. Standard Fibre Tip Plotter Pens and even ordinary low cost Ball Pens! More CompatibleSupport different HPGL languages by a wide array of popular CAD software Plotter Specification: JD-P-110 JD-P-165 JD-P-185 JD-P-230 Paper Width Max 1050mm 1700mm 1900mm 2250mm Plot Width Max 950mm 1650mm 1850mm 2200mm Plot Length Max Unlimited Variable Paper Sizes: 24" to 36" 36" to 63" 36" to 73" 36" to 86" Paper Roll Dia. Max: 6.5"(16cm) 6.5"(16cm) 6.5"(16cm) 9"(22cm) Roll Feed & Take-up: Roll Feed YES Plotting Speed 40-90 cm/s Addressable Resolution 0.025 mm Accuracy 0.1 or 0.1% Language HPGL Port / Interface COM or LPT Input Voltage 110 - 230 Volts Pen type Biro, Bic Type, plotting pen, Ball pen and fountain pen or RP Professional Pen Operating Temp. 0 - 40 Degree (32 - 104F) Operating Humidity 35% - 80% non-condensing Drawing paper Type 50g - 110g drawing paper Control and driving circuit 16 Bit double CPU, 1MB cache memory. Stepping motor Control panel Menu, LCD indicator. Three level menu One year 100% Parts Warranty Free is available.Lifetime customer support in technology and providing of spare parts are available.We reserve the right to change specifications for product improvement without prior notice.Referrible packing size for RP Streamline 200: 2420*530*450(mm) Weight 135kg
More Stylish and StableMore streamline appearance makes a better look, and newer metal materials in the plotter head can avoid the static when the plotter is working.
More AffordableProvide you a wide selection of pen types i.e. Standard Fibre Tip Plotter Pens and even ordinary low cost Ball Pens!
More CompatibleSupport different HPGL languages by a wide array of popular CAD software
