Speed Dome Camera (U2S-SP9306)

Detailed Product Description

Model	U2S-SP9306
Sync System	PAL standard : 625 lines, 21 per second, 2:1 Interfacing
Imaging sensor	1/4" Sony Super HAD CCD
Effective Image (H X V)	380,000
Resolution	420 lines / 480 lines (optional)
Video output	1.0±0.2Vp-p
S / N	≥50 db
Illumination	Color 0.5 Lux
White Balance	Automatic / manual
Zoom Length	3.7mm/6mm (optional)
Electronic shutter	1 / 50-1 / 120, 000 seconds
Pan rotation range	360 ° continuous rotation
Tilt rotation range	0 ~ 90 ° with auto-flip
Pan speed	0.5° ~ 160°/ s
Tilt speed	0.5° ~ 90° / s
Presets	128
Decoders	Built - in
Baud rate (RS485/422)	2400/4800/9600/19200 bps
ID range	1～254
Operation Temperature	0°～50°
Environmental Humidity	0 ~ 95％ (non-condensing)
Power Supply	DC12V/1A
Power consumption (W)	≤ 9 W
Dimensions (H X D)	120 X 160 (mm)
Communication	RS485/422 Bus
Protocol	Built-in multi-protocol (Pelco-P/D)
Net weight	1.1 (kg)
Gross Weight	1.5 (kg)
