Structured Corrugated Ceramic Packing

Detailed Product Description

Characteristic

High capacity owning to that new tower design may reduce diameter while revamping old towers may increase capacity significantly.
High separation efficiency owing to much large specific surface area compared to random packing.
Low pressure drop which leads to reduction of energy consumption largely.

Application

　　1.Rectify absorption of corrosion mixture which has certain requirement of pressure drop and number of theoretical plate;
　　2.Vacuum operation with the absolute pressure is above 100Pa;
　　3.Rectify of halide organic compound;
　　4.Used as heat exchanger, mist eliminator or catalyst carrier and so on;
　　5.Be applied to the reconstruction of large-scale tower because it reduces the carrying capacity.　

Major Technical Parameters
Type X	100X	125X	150X	250X	300X	400X	450X
Type Y	100Y	125Y	150Y	250Y	300Y	400Y	450Y
Void Volume %	85.5	85	85	74	72	70	68
Bulk Density kg/m³	370	400	42	620	650	670	700

Tips: X = 30° (Corrugated Angle of Inclination), Y = 45° (Corrugated Angle of Inclination). The number front of X/Y means the packing’s specific surface area （m²/m³）.

Place of Origin:

Jiangxi in China
