HOWO 6*4 tractor

Model:

ZZ4187N3511V

Engine

Make:SINOTRUCK

4-stroke direct injection diesel engine

Engine model:WD615.69,Euroemission standard

6-cylinder in-line with water cooling,turbo-charging and intercooling

Maximum output:336hp(247kw) at 2200 rpm according to DIN

Maximum torque:1350Nm at 1100-1600 rpm

Displacement:9.726L

Bore:126mm

Stroke:130mm

Specific fuel consumption:195g/kwh

Engine oil filling quantity(long term filling):40L

Thermostat with 80 opening begin

Clucth

Single-plate dry coil-spring clutch,diameter 420mm,hydrqulically operating with air assistance

transmission

Model:HW9,synchromesh,9 forward &1 reverse

Propeller shaft

Double universal joint propeller shaft with gear-shaped coupling flange

Front axles

Steering with double T-cross section beam

Rear axles

Pressed axle housing,central single reduction with hub reduction and with differential locks between wheels and axles

Chassis

Frame: U-profile parallel ladder frame with section of 300*80*8mm,all cold riveted cross members

From suspension;9 semi-elliptic leaf springs wth width of 90mm,hydraulic telescopic double-action dhock absorbers and stablilizer

Rear suspension:15 leaf semi-elliptic springs with width of 90mm and bogic spring

Steering

ZF power steering.model ZF8098,hydraulic steering with power assistance

Brakes

Service brake:dual circuit compressed air brake

Parking brake(emergency brake):spring energy,compressed air operating on rear wheels

Auxiliary brake:engine exhaust brake

Wheel&types

Rims:8.5-20,10 hole-steel  Tyres:12.00R20 Radial tires

Drivers cab

Standard cab,all-steel forward control,70 hydraulically titable on the front,2-arm windscreen wiper system with three speeds,laminated windscreen with casted-in radio aerial,hydraulically damped adjustable drivers seat and rigid adjustable co-drivers seat ,with heating and ventilating system,exterior sun visor,adjustable roof flap, stereo radio/cassette recorder,safety belts,adjustable steering,air horn amd air conditioner

Electrics

Operating voltage:24V,negative grounded

Starter: 24V,7.5kw according to ISO 8856 at temperature of 20

Alternator:3-phrase,28V,1540W

Batteries:2*12V,135Ah/180Ah

Dimension in mm

Wheel base                                               3500

Front overhang                                            1939

Rear overhang                                             1800

Overall length                                             6110

Overall width                                             2480

Overall height                                             3668

Weight in kg

Permissible loading capacity                                 7210

Chassis dead weight                                       11645

Gross vehicle weight                                       19000

Performance

Maximum driving speed(km/h)                                102

Maximum gradeability(%)                                    30
