ZL30G ZL30B ZL40B Wheel Loader

Next Product

Detailed Product Description

1. Engines with low petrol consumption, less exhaust, less noise.

2. Fixed-axis electrical controlled gearbox, ZF electrical control system, easy operation.

3. Double-pumping, energy saving and high efficiency, sensing swiveling system.

4. Air valve control emergency braking system, safe and sound for halting and braking.

5. Integrated compound materials cover, elegant appearance, easy maintenance.

6. Luxury driving cab with an open view, sealed , less vibration, air-conditioned, comfortable, and safe.

Item	ZL40B	ZL30B	ZL30G
Rated shovel volume m3	2.2	1.7	1.7
Rated load t	4	3	3
Operational weight t	13.5	10	10.2
Shovel auto go flat	YES	YES	YES
Max. shovel force KN	107.8	88	103
Max. pulling force	105	80	90
Max. climbing angles	25°	25°	25°
Shovel ascent time s	6.5	6	5
Shovel descent time s	3.5	3.5	3.34
Shovel front tilting time s	1.3	1.3	1.54
Engine
Model	T6130G1B	6102BG	6110/125G5-14
Rated power/rpm	125KW/2200	80.9KW/2200	88KW/2200
Type	6-cylinder vertical water cooling	6-cylinder vertical water cooling	6-cylinder vertical water cooling
Conveyor system
Distance adjustor	Single step,four components	Single step,three components	Single step,three components
Gearbox	Planet-type power gearing	Gearing	Fixed axis electrical gearing
Gears	Forward 2 Backward 1	Forward 4 Backward 2	Forward 3 Backward 3
Max. speed	35	35	34.5
Tyre	20.5-25	17.5-25	17.5-25
Turning system
Type	Full hydraulic reverse device	Full hydraulic reverse device	Priority unloading order for the Load censor reverse device
Turning angles	35°	35°	35°
Min. turning radius mm	5650	5400	5650
Hydraulic system working pressure	16	16	16
Braking system
Running brake	Pneumatic clamp plate	Pneumatic clamp plate	Pneumatic Full hydraulic clamp plate
Parking brake	Air-off control hoof	Hoof	Air -off control clamp
Emergency brake	Air -off control hoof	Hoof	Mechanism
Voltage	24V	24V	24V
