Standard-Type Electric Strike (CSYS130)

1. Lock Size: 150Lx39. 5Wx28H(mm)

2. Bolt structure: Stainless Steel

3. Holding Stength: 800kg

4. Voltage: DC12V

5. Current: 450mA(CSYS-130NO) 200mA(CSYS-130NC)

6. Feature: Fail Secure(CSYS-130NO) Fail Safe(CSYS-130NC)

7. Surface Temperature: Within +20℃

8. Suitable Temperature: -10～+25℃(14-131F)

9. Face plate Housing: Painted Steel

10. Bolt Housing: Stainless steel, Draw the Polishing of silk

11. Funtion: Built-out MOV

12. Suitable For: Wooden Door, Metal Door, PVC Door

13. Opening Mode: 90 Degree Swinging Door

14. Weight: 0. 3kg

15. Standard Packing: 60pcs/box

Features:

1. Holding 800kg

2. Aluminum, Stail Steel Bolt

3. Testing to 1000000 cycles

4. High-Temperature Painted, Duable and Beatifu Artical

5. CE Certificate by European Union, MA Certificate by China Public Security office
