Insulation Piercing Connector (JMA4-150)

Insulated piercing clamp for aerial bundled cable

Type: JMA4-150

Main: 50 -150 mm²

Tap: 50 - 150 mm²

Feature

1) Simple installation, small contact resistance and low temperature rise of the clamp.

2) The applicable voltage is 10 KV, 1 KV or less than 1 KV.

3) Piercing connector, simple installation, need not strip the cable coat.

4) Moment nut, piercing pressure is constant; keep good electric connection and make no damage to lead.

5) Self-seam frame, water proof, and anti-corrosion, extend the using life of Insulated lead and connector.

6) Adopted special connecting tablet, apply to joint of Cu (Ai) and Cu (Ai) or Cu and Ai.

7) Small electric connection resistance, impulse current can be up to 15 ka.

 8) Special insulated case body, resistance to illumination and environmental aging, the insulation strength can up to 6 kv.

9) AAC surface design, applied to connection with the same (different) diameter, wide connection scope from 0.75 mm² to 400 mm^2.
