Full-Insulated Middle Terminal (HT-6-12)

Detailed Product Description

Features:

1) Product name: long/short full-insulated middle terminal.

2) Material: purple terminal

3) Size:

Material: Copper Insulating Material: PVC
ITEMNO	Section of lead		Dimension (mm)			Max current	Color
ITEMNO	A.W.G	mm2	l	dΦ	L	Max current	Color
BV 1.25	22 - 16	0.5 - 1.5	15.0	1.7	26.0	19A	red
BV 2	16 - 14	1.5 - 2.5	15.0	2.3	26.0	27A	blue
BV 5.5	12 - 10	4 - 6	15.0	3.4	26.0	48A	yellow
BV 8	#8	6 - 10	21.0	4.5	32.0	62A	red
BV 14	#6	10 - 16	26.0	5.8	42.0	88A	blue
BV 22	#4	16 - 25	29.0	7.7	50.0	115A	yellow
BV 38	@2	35 - 50	32.0	9.4	55.0	160A	red

4) Packing: 100pc per bag,carton for outer packing, customer's special packings are available.

Place of Origin:	Zhejiang in China
Model No:	HT-6-12
Brand Name:	Hont
Payment Terms:	L/C,T/T(Bank Transfer),Western Union,
