1 Number of Layers 1-30Layers
2 Finished Boards Thickness 0.2mm-6.0mm
3 Max.Panel size 610mm X 1200mm
4 Available Laminates Material FR1,FR2,CEM1,CME3,FR-4, High TG FR-4,PTFE,Aluminum Base, Rogers,Tachnic, Halogen Free,high-frequency,Leadfree and so on.
6 Min Line Width/Spacing 3mil/3mil(0.075mm/0.075mm)
7 Drilling Hole (Mechanical) 0.15mm--6.35mm
8 Finish Hole (Mechanical) 0.10mm--6.30mm
9 Diameter Tolerance (Mechanical) 0.05mm
10 Registration (Mechanical) 0.075mm
11 Out Layer Copper Thickness 35um--280um
12 Inner Layer Copper Thickness 17um--210um
13 Aspect Ratio 12:1
14 SMT Mini. Solder Mask Width 0.08mm
15 Mini. Solder Mask Clearance 0.05mm
16 Plug Hole Diameter 0.25mm--0.60mm
17 Impedance Control Tolerance +/-5%
18 Surface Finish HASL,HASL Leadfree,Immerstion ENIG,Chem. Tin,Flash Gold,OSP,Gold finger,Peelable,Immerision Silver,
19 Insulation Layer Thickness 0.075mm--5.00mm
20 Special technology Blind hole PCB,Buried via PCB, Impedance control PCB,Heavy Cu PCB (8oz)
More than 15 years experience of manufacturing PCB Provide you not only the prototype but PCB with big quantity at competitive prices Lead time for urgent prototype: 2 layers- in ONE day, multilayers- in 4 days.
We are sincerely hope that you can give me a chance to prepare a quotation for you, then you can know how we can help you to be more competitive inElectronics Market. And welcome to your prototype/sample orders for testing our quality.
| Place of Origin: | Guangdong in China |
| Model No: | PCB |
| Brand Name: | Rigid pcb,flexible pcb,Rigid-flexible pcb |
| FOB Price: | 0.812-0.901 USD Hong Kong |
| Other Price Terms: | DDU,DDP,FCA |
| Payment Terms: | L/C,T/T(Bank Transfer),PayPal, |
| Minimum Order: | Piece/Pieces 10 |
| Supply Ability: | Square Meter|8000|Month |
| Package: | per customer's requirements |
| Delivery Time: | 10-15days. |
