1. The ideal working pressure: 0.1-0.5Mpa
(A protection value shall be used if the supply pressure exceeds 0.5Mpa)
2. Cold Water supply temperature: 4-29 degrees centigrade.
Hot water supply temperature: 55-85 degrees centigrade.
(Working temperature in use from 55- 65 degrees centigrade is suggested
3. Outlet water temperature range: 20- 49 degrees centigrade.
4. Set the safety temperautre at 38 degrees centigrade.
5.Safety Characteristic:
If cold water supply fails,flow rate would drop rapidly even shut down,and the outlet temperature decreases to safety temperature range.
6.Complies with Stadards:
ASSE 1016-2005,ASME A112.18.1-2005/CSA B125.1-05,EN1111,EN1287,QB2806-2006
