Auto-grommet Machine (CS-DK-SQ)

Introduction:

Auto-grommet machine is fully automatic to perform grommet collecting, feeding, punching and press-in all together. The working condition is convenient to switch either on the table or ground. Its small size and weight make it possible to working on the ground, which greatly release the working intension. Applicants cover grommet for billboard, tents, and tarpaulins.

Specification:

* Max input power: < 150 VA

* Voltage: Single phase 50Hz, 220V+ - 10%

* Air requirement: 8 bar

* Grommet speed: 1000 PCS/Hour

* Grommet model supported: No. 5

* Neighbor grommet distance: 12 to 22 mm

* Cylinder number: Double

* Shape size: 450x500x460(mm)

* Carton size: 620x590x470(mm)

* N. W. : 60kg

* G. W. : 62kg

* Certification: CE

Remark:

No. 5 eyelet: inner diameter 10mm, outside diameter 19mm Applicable for iron grommets
